Zoom F1-SP Field Recorder & Shotgun Microphone
F1-SP FEATURES
* Two-channel audio recorder * Compatible with Zoom microphone capsules * Supports up to 24-bit/96 kHz audio in BWF-compliant WAV or a variety of MP3 formats * One-touch button controls * 1.25” monochrome LCD display * Rec Hold function to avoid accidental operation of buttons * Stereo ⅛" Mic/Line In mini phone jack with Plug-in power (2.5V) * Stereo ⅛" Phone/Line Output jack with dedicated volume control * Built in limiter and auto level control to avoid clipping * Pre-Record function * Tone generator for calibrating audio levels between the F1 and a DSLR or video camera without the need for an attenuator cable * Sound marker function that outputs quick tone to make syncing audio and video easy * Records directly to micro SD and SDHC cards up to 32 GB * Micro USB port for data exchange to and from computer and use as an audio interface with computer or iOS device * Runs on only 2 standard AAA alkaline, Lithium, or NiMH rechargeable batteries, or AC adapter (AD-17) * Up to 10 hours of operation with alkaline batteries (when using lavalier)
SPECS General
* RECORDING MEDIA microSD/microSDHC cards | (Class 4 or higher, up to 32 GB) * RECORDING FORMATS WAV: 44.1 kHz/16-bit, 48 kHz/16-bit, 48 kHz/24-bit, 96 kHz/24-bit MP3 : 48 kbps, 128 kbps, 192 kbps, 256 kbps, 320 kbps Mono/stereo ID3v1 tags supported * DISPLAY 1.25" monochrome LCD INPUTS MIC IN ZOOM mic capsule input MONO SHOTGUN * MIC (SGH-6) Directionality: Super cardioid (3 directional mic units) * Sensitivity: −39 dB/1 Pa at 1 kHz | Input gain: −∞ – +50 dB * Maximum sound pressure input: 122 dB * SPL MIC/LINE IN Connector: 3.5 mm stereo mini (with screw lock) * Supports plug-in power (2.5 V) | Input gain: −12 dB – +36 dB * Input impedance: 2 kΩ or more OUTPUTS PHONE OUT Connector: 3.5 mm stereo mini (with screw lock) | Maximum output level: 11 mW + 11 mW (into 32 Ω load) * USB microUSB : Mass storage operation: USB 2.0 High Speed * Audio interface operation: USB class compliant 44.1kHz/16-bit, 48kHz/16-bit, 2-in/2-out * Transfer method: asynchronous POWER 2 AAA batteries (alkaline, NiMH or lithium) AC adapter (ZOOM AD-17): DC 5V/1A *| RECORDING TIME USING BATTERIES SGH-6 mono shotgun mic capsule (48 kHz/24-bit |, mono): Alkaline batteries: about 6.5 hours NiMH batteries 750 mAh): about 6 hours | Lithium batteries: about 11 hours *The above values are approximate.
WHAT'S IN THE BOX
* F1 Field Recorder
* LMF-1 Lavalier microphone
* WSL-1 Windscreen
* MCL-1 Mic clip * BCF-1 Belt clip
* 2x AAA batteries
* Quick guide.
Zoom F1 Field Recorder & Lavalier Microphone
Complete your story with the audio quality it deserves
The Zoom F1 Field Recorder + Lavalier Mic is the perfect solution for videographers who need to capture the nuance of every word with professional quality audio.
Features
Two-channel audio recorder
Compatible with Zoom microphone capsules
Supports up to 24-bit/96 kHz audio in BWF-compliant WAV or a variety of MP3 formats
One-touch button controls
1.25” monochrome LCD display
Rec Hold function to avoid accidental operation of buttons
Stereo ⅛" Mic/Line In mini phone jack with Plug-in power (2.5V)
Stereo ⅛" Phone/Line Output jack with dedicated volume control
Built in limiter and auto level control to avoid clipping
Pre-Record function
Tone generator for calibrating audio levels between the F1 and a DSLR or video camera without the need for an attenuator cable
Sound marker function that outputs quick tone to make syncing audio and video easy
Records directly to micro SD and SDHC cards up to 32 GB
Micro USB port for data exchange to and from computer and use as an audio interface with computer or iOS device
Runs on only 2 standard AAA alkaline, Lithium, or NiMH rechargeable batteries, or AC adapter (AD-17)
Up to 10 hours of operation with alkaline batteries (when using lavalier)
Specs
Recording Media: MicroSDHC cards
*(Class 4 or higher, up to 32 GB)
Recording Formats: WAV
* 44.1 kHz/16-bit, 48 kHz/16-bit, 48 kHz/24-bit, 96 kHz/24-bit*MP3 : 48 kbps, 128 kbps, 192 kbps, 256 kbps, 320 kbps*Mono/stereo ID3v1 tags supported.* DISPLAY: 1.25" monochrome LCD
INPUTS
*MIC IN : Connector: 3.5 mm stereo mini (with screw lock) * Supports plug-in power (2.5 V) *Input gain: −12 dB – +36 dB *Input impedance: 2 kΩ or more *LAVALIER MIC : Plug: 3.5 mm stereo mini (with screw lock) *Directionality: Omnidirectional *Sensitivity: -32 dB/1 Pa at 1kHz *Maximum sound pressure input: 115 dB spl *Cable length: 160 cm
OUTPUTS
*PHONE OUT : Connector:3.5 mm stereo mini (with screw lock)* Maximum Output level: 11 mW + 11 mW (intp 32Ω load)*USB: MicroUSB* Mass storage operation: USB 2.0 High Speed*Mass storage operation: USB 2.0 High Speed* 44.1kHz/16-bit, 48kHz/16-bit, 2-in/2-out*44.1kHz/16-bit, 48kHz/16-bit, 2-in/2-out*Transfer method: asynchronous
