Active DI Box with Extended Dynamic Range
Product Features
Active DI box with high-headroom design and +48 V phantom power for extended dynamic range
Fully transformer-isolated design ensures electrical separation between PA and stage equipment
Balanced line input on Neutrik* XLR and high impedance input and link output on 1/4" TRS connectors
20 dB input pad and earth lift switches
Aluminium extrusion casing with protective rubber corners
Compact and rugged design
DN100
The DN100 has become an established favourite amongst both engineers and musicians alike. With its high headroom, dynamic response and sonic clarity, DN100 faithfully reproduces the character of electric and acoustic instruments and allows far more of the detail of musical performances to be captured. DN100 is intended for professional applications where +48 V phantom power is a standard feature on all mixing consoles, and its innovative design results in a significantly higher clipping point than many other active DI Boxes, providing +10 dBu output into a 2 kΩ load. This increased headroom means that much higher-level input signals can be accommodated without the need for an attenuating pad. Combined with a very low noise input circuit topology, DN100 offers a very wide dynamic range, and only requires a single -30 dB pad for use when connecting directly to instrument amplifier outputs.
DN100 is built to handle the rigours of life on the road, a thick aluminium extrusion protects the electronics, and in turn is covered by a tough silicone rubber sleeve.
Balanced Transformer-Isolated Output
Exhaustive listening tests using a wide variety of active and passive bass guitars, electro-acoustic guitars and electronic musical instruments were carried out to select the components for DN100 to achieve the best musical sound. Not only was the choice of the audio transformer particularly important in achieving this goal, but the impedances of the surrounding components were also highly critical in getting the best possible performance out of the audio transformer. The line-driving characteristics of the transformer output were carefully optimised to provide the best frequency and phase responses for short and long cables and widely differing line and termination impedances.
Care was taken in the design of the DN100 to avoid audio transformer core saturation and a fixed high pass filter has been included in the signal path to roll off frequencies below those that are musically important. The lowest note on a 5- or 6-string bass guitar is B0 with a frequency of 30.87 Hz, and the lowest note on an 88-key piano keyboard is A0 with a frequency of 27.50 Hz. DN100 still maintains a frequency response of ±0.5 dB at these lowest musical notes.
As well as the transformer in the signal path, DN100 also has a transformer to isolate the power rails to the input circuit from the phantom power supply sourced from the output XLR connector. When used in conjunction with the Earth Lift switch, this full galvanic isolation of input and output interfaces ensures that any risk of earth loops is avoided when taking a direct feed from stage backline equipment.
Dual-Impedance Inputs
A custom instrumentation-grade input circuit was designed for the DN100 using advanced analogue design techniques to create the very high input impedance required by passive guitar and bass pickups, whilst keeping the actual component values low to minimise noise. This innovative approach to circuit design produces a very low noise floor, which combined with the high clipping point creates an unrivalled dynamic range in a +48 V phantom powered DI Box.
DN100 features one parallel-connected XLR and two ¼" TRS inputs, one which may also be used a link output for connection to a guitar or bass amplifier. When connecting to the XLR input only, the input impedance is 20 kΩ, ideal for line level equipment and offering even lower noise performance. This input impedance is far too low for guitar and bass pickups and is removed from the circuit when a jack plug is inserted into a ¼" TRS input, resulting in a nominal 1 MΩ input impedance, ideal for passive electric pickups.
Illuminated 30dB Pad and Earth Lift Switches
DN100 features illuminated Pad and Earth Lift switches, which along with the +48V phantom power indicator LED, provide ‘at a glance’ status display, even at wide distances and viewing angles.
The Earth Lift switch separates the input and output grounds, useful in eliminating earth loops between equipment on different mains electricity supplies.
Built for the Road
Featuring a tough aluminium extrusion, the DN100 is designed for the rigours of live concert touring. The protective rubber corners also insulate the DN100 chassis to further enhance its electrical isolation. Premium Neutrik XLR connectors are used to ensure reliable audio connections, night after night.
Please be informed that this item comes with an international adaptor, you will need to get SA converter for it.
2.4 GHz Wireless Stereo Transmitter for High-Performance Stereo Audio Broadcasting
Product Features
Stereo transmitter to wirelessly stream audio (together with separate DW 20R)
Perfect for hospitality and event spaces, retail and home audio, etc.
Able to broadcast to multiple receivers (not included)
Digital 2.4 GHz wireless connectivity offers superior sound quality
High headroom design offers superior sound quality
Maximum wireless range 100 feet (30 m)
External, articulating antenna ensures optimum transmission and reception
Aluminium extrusion casing with protective rubber corners
Floor and wall mount brackets for fixed installation (included)
High quality Neutrik* XLR and 1/4" TRS connectors
4 GHz ISM band operation allows license-free use on a worldwide basis
Compact and rugged design
Designed and engineered in the U.K.
AIR LINK DW 20T
When used in conjunction with DW 20R Wireless Receivers, the AIR LINK DW 20R Wireless Stereo Transmitter brings the convenience of high-performance audio-streaming to any installed or portable sound system, making it ideal for hospitality and event spaces, as well as retail, home audio, and much more.
Featuring a maximum wireless range of 100 feet (30 m), DW 20R is easy to use and utilises premium-grade Neutrik balanced XLR and unbalanced 1/4" TRS connectors to cover a wide range of audio applications.
Superior Performance
Thanks to its high headroom design, the DW 20T transmitter provides pristine audio streaming that is far superior to competing products. Care has been taken in both the design process and component selection to ensure the highest-quality performance in its class.
Maximum Range and Flexibility
Aided by an external articulated antenna, the DW 20T is designed to provide dependable transmission over an astounding range of up to 100 feet (30 m). Multiple receivers can be deployed to provide targeted zone broadcasting, as long as each DW 20R is paired with only one DW 20T device at a time – allowing unique content to be streamed concurrently across each of the individual zones.
Robust Construction
Housed in a compact and rugged aluminium extrusion enclosure, the DW 20T transmitter can be permanently installed via the included floor/wall mount brackets, or placed securely on a shelf thanks to its rubber corner protectors. Connectivity options include high quality Neutrik* XLR and 1/4" TRS input sockets, ensuring a crystal-clear signal path to professional mixers, amplifiers, or powered loudspeakers.
Single Streaming Solution
Engineered by the Award-winning Klark Teknik design team, the DW 20T is sublimely easy to use – and is the single audio streaming solution for a broad variety of applications.
Passive Stereo DI Box with Midas Transformer and Extended Dynamic Range
Product Features
Passive stereo DI Box for general purpose applications
Custom-built Midas transformer for highest signal integrity
High headroom design offers superior sound quality
Passive design does not require any power supply
Stereo inputs on 1/4" TS connectors
Through connectors on 1/4" TS connectors
Switchable input attenuation for guitar, line and speaker levels
High quality Neutrik* XLR connectors
Earth Lift switch eliminates ground loop problems
Fully transformer-isolated design ensures electrical separation
Ultra-low noise and ultra-linear system for highest signal integrity
Aluminium extrusion casing with protective rubber corners
Compact and rugged design
Designed and engineered in the U.K.
PRO DI 2 DI 20P
Building on KLARK TEKNIK’s storied legacy of highest-quality direct injection devices, the DI 20P PRO DI 2 offers the same high headroom, dynamic response and sonic clarity you have come to expect. DI 20P is ideal for interfacing stereo keyboards, samplers and other electronic musical instruments to mixing consoles, and faithfully reproduces the character of electric and acoustic instruments, allowing far more of the detail of musical performances to be captured.
A passive device, the DI 20P does not require any form of external power to complete its mission. Equipped with a custom-built MIDAS transformer and switchable input Pad, DI 20P easily accommodates instruments, line, and even loudspeaker level signals – making it the perfect choice for professional audio and multimedia applications.
MIDAS – The Legend in Sound Quality
Ever since its formation in the 1970s, MIDAS has had a long history of innovation and leadership in the world of audio mixing consoles. Employed by the most famous touring acts and installations world-wide, legendary MIDAS consoles such as the XL4 and Heritage H3000 quickly became industry standards.
MIDAS has earned their impeccable reputation due to their no-compromise approach for audio and build quality and in particular for their Award-winning products which are considered by industry experts as the industry’s best sounding designs.
Building on this legacy, the XL8 and PRO Series of Live Mixing Systems continue this great heritage of Award-winning audio quality.
KLARK TEKNIK is proud to incorporate MIDAS designed transformers for the ultimate in high-quality audio reproduction in both live and studio environments. Find out more about MIDAS’ amazing legacy by visiting their extensive website.
Compact & Rugged Construction
The ultra-compact DI 20P is built to handle the rigours of life on the road via a thick and rugged aluminium extrusion that protects the electronics. The enclosure’s roadworthiness is further enhanced through the implementation of sturdy rubber corner bumpers.
High Headroom Design
A custom instrumentation-grade input circuit was designed for the DI 20P using advanced analogue design techniques to create the ideal input impedance match. This innovative approach provides an ultra-low noise, low harmonic and phase distortion input stage with a ruler-flat frequency response that ranges from 20 Hz to 30 kHz (±1 dB).
Connectivity & More
DI 20P PRO DI 2 features genuine high quality Neutrik* XLR and high impedance 1/4" TS connectors to maintain the highest signal integrity. The Input connectors accept unbalanced signals over 1/4" TS cables, with the Thru jacks passing unbalanced 1/4" TS signals to local amps/monitors.
The Output XLR jacks send balanced versions of the input signals to your mixing board or other processing device.
Input Pad, Earth Lift Switch & More
A -15 dB input Pad enables the DI 20P to easily accommodate a wide range of input signals including guitar, line and speaker levels (up to 30 dBu). The onboard Earth Lift switch separates the input and output grounds, eliminating earth loops between equipment on different mains electricity supplies.
DI 20P’s fully transformer-isolated design further ensures pristine performance – even in large-scale production environments.
Versatility
The DI 20P PRO DI 2 provides maximum versatility, frequency response from 20 Hz to 30 kHz (�1 dB), MIDAS custom-design transformers for the ultimate signal integrity, and much more � all in a road-ready enclosure that stands ready for your input.
Passive DI Box with Stereo Input / Summed Mono Output, Midas Transformer and Extended Dynamic Range
Product Features
Passive DI Box with stereo input and summed mono output
Custom-built Midas transformer for highest signal integrity
High headroom design offers superior sound quality
Passive design does not require any power supply
Stereo input on 1/8" TRS and RCA connectors
Fully adjustable level control for both channels
High quality Neutrik* XLR connector
Earth Lift switch eliminates ground loop problems
Fully transformer-isolated design ensures electrical separation
Ultra-low noise and ultra-linear system for highest signal integrity
Aluminium extrusion casing with protective rubber corners
Compact and rugged design
Designed and engineered in the U.K.
PRO DI DI 10P
Building on KLARK TEKNIK’s storied legacy of highest-quality direct injection devices, the DI 10P PRO DI offers the same high headroom, dynamic response and sonic clarity you have come to expect. DI 10P is ideal for interfacing MP3, CD players, keyboard or drum sub mixers, and a variety of other stereo sources to mixing consoles.
A passive device, the DI 10P does not require any form of external power to complete its mission. Equipped with a custom-built MIDAS transformer, fully adjustable independent level controls for the stereo input channels, DI 10P is the perfect stereo to mono XLR solution for professional audio and multimedia applications.
MIDAS – The Legend in Sound Quality
Ever since its formation in the 1970s, MIDAS has had a long history of innovation and leadership in the world of audio mixing consoles. Employed by the most famous touring acts and installations world-wide, legendary MIDAS consoles such as the XL4 and Heritage H3000 quickly became industry standards.
MIDAS has earned their impeccable reputation due to their no-compromise approach for audio and build quality and in particular for their Award-winning products which are considered by industry experts as the industry’s best sounding designs. Building on this legacy, the XL8 and PRO Series of Live Mixing Systems continue this great heritage of Award-winning audio quality.
KLARK TEKNIK is proud to incorporate MIDAS designed transformers for the ultimate in high-quality audio reproduction in both live and studio environments. Find out more about MIDAS’ amazing legacy by visiting their extensive website.
High Headroom Design
A custom instrumentation-grade input circuit was designed for the DI 10P using advanced analogue design techniques to create the ideal input impedance match. This innovative approach provides an ultra-low noise, low harmonic and phase distortion input stage with a ruler-flat frequency response that ranges from 10 Hz to 91 kHz (± 1 dB).
Connectivity & More
DI 10P PRO DI features unbalanced stereo Left & Right RCA and 1/8" TRS Input connectors, and a high quality Neutrik* Output XLR jack that sends a balanced, summed mono version of the input to your mixing board or other processing device.
Input Controls & Earth Lift Switch
Featuring high-precision Left and Right Level controls, the DI 10P easily accommodates a wide range of input signals. The Earth Lift switch separates the input and output grounds, eliminating earth loops between equipment on different mains electricity supplies. DI 10P’s fully transformer-isolated design further ensures pristine performance – even in large-scale production environments.
Compact & Rugged Construction
The ultra-compact DI 10P is built to handle the rigours of life on the road via a thick and rugged aluminium extrusion that protects the electronics. The enclosure’s roadworthiness is further enhanced through the implementation of sturdy rubber corner bumpers.
Versatility
The DI 10P PRO DI provides maximum versatility thanks to its incredible frequency response of 10 Hz to 91 kHz (± 1 dB), a MIDAS custom-design transformer for the ultimate signal integrity, stereo to mono summing, and much more – all in a road-ready enclosure that stands ready for your input.
Please be informed that this item comes with an international adaptor, you will need to get SA converter for it.2.4 GHz Wireless Stereo Receiver for High-Performance Stereo Audio Broadcasting
Product Features
Stereo receiver to wirelessly stream audio (together with separate DW 20T)
Perfect for hospitality and event spaces, retail and home audio, etc.
Apply multiple DW 20R units for larger coverage
Digital 2.4 GHz wireless connectivity offers superior sound quality
High headroom design offers superior sound quality
Maximum wireless range 100 feet (30 m)
External, articulating antenna ensures optimum transmission and reception
Aluminium extrusion casing with protective rubber corners
Floor and wall mount brackets for fixed installation (included)
High quality Neutrik* XLR and 1/4" TRS connectors
4 GHz ISM band operation allows license-free use on a worldwide basis
Compact and rugged design
Designed and engineered in the U.K.
AIR LINK DW 20R
When used in conjunction with the DW 20T Wireless Transmitter, the AIR LINK DW 20R Wireless Stereo Receiver brings the convenience of high-performance audio-streaming to any installed or portable sound system, making it ideal for hospitality and event spaces, as well as retail, home audio, and much more.
Featuring a maximum wireless range of 100 feet (30 m), DW 20R is easy to use and utilises premium-grade Neutrik balanced XLR and unbalanced 1/4" TRS connectors to cover a wide range of audio applications.
Superior Performance
Thanks to its high headroom design, the DW 20R receiver provides pristine audio streaming that is far superior to competing products. Care has been taken in both the design process and component selection to ensure the highest-quality performance in its class.
Maximum Range and Flexibility
Aided by an external articulated antenna, the DW 20R is designed to provide dependable reception over an astounding range of up to 100 feet (30 m). Multiple receivers can be deployed to provide targeted zone broadcasting, as long as each DW 20R is paired with only one DW 20T device at a time – allowing unique content to be streamed concurrently across each of the individual zones.
Robust Construction
Housed in a compact and rugged aluminium extrusion enclosure, the DW 20R receiver can be permanently installed via the included floor/wall mount brackets, or placed securely on a shelf thanks to its rubber corner protectors. Connectivity options include high quality Neutrik* XLR and 1/4" TRS output sockets, ensuring a crystal-clear signal path to professional mixers, amplifiers, or powered loudspeakers.
Single Streaming Solution
Engineered by the Award-winning Klark Teknik design team, the DW 20R is sublimely easy to use – and is the single audio streaming solution for a broad variety of applications.
Active DI Box with Midas Transformer, Extended Dynamic Range and Phantom/Battery Operation
Product Features
Active DI Box for general purpose and multimedia applications
Custom-built Midas transformer for highest signal integrity
High headroom design offers superior sound quality
Powered from console +48 V phantom or internal battery (not included)
Automatic switchover to battery if phantom power fails
Matches the level and impedance with unity gain without loading the source
Switchable input attenuation for guitar, line and speaker levels
High quality Neutrik* XLR and high impedance 1/4" TRS connectors
Earth Lift switch eliminates ground loop problems
Fully transformer-isolated design ensures electrical separation
Ultra-low noise and ultra-linear system for highest signal integrity
Aluminium extrusion casing with protective rubber corners
Compact and rugged design
Designed and engineered in the U.K.
PRO DI ACTIVE DI 10A
Building on KLARK TEKNIK’s storied legacy of highest-quality direct injection devices, the DI 10A PRO DI ACTIVE offers the same high headroom, dynamic response and sonic clarity you have come to expect.
DI 10A is ideal for interfacing keyboards, samplers and other electronic musical instruments to mixing consoles, and faithfully reproduces the character of electric and acoustic instruments, allowing far more of the detail of musical performances to be captured.
The DI 10A is powered by +48 V phantom power with a 9 V battery backup, which automatically allows the device to function should phantom power fail, or be unavailable. Equipped with a switchable input attenuator, DI 10A easily accommodates instruments, line, and even loudspeaker level signals – and thanks to its extremely low noise input circuit topology (-112 dBu), DI 10A provides extended dynamic range, making it the perfect choice for professional audio and multimedia applications.
Compact & Rugged Construction
The ultra-compact DI 10A is built to handle the rigours of life on the road via a thick and rugged aluminium extrusion that protects the electronics. The enclosure’s roadworthiness is further enhanced through the implementation of sturdy rubber corner bumpers.
MIDAS – The Legend in Sound Quality
Ever since its formation in the 1970s, MIDAS has had a long history of innovation and leadership in the world of audio mixing consoles. Employed by the most famous touring acts and installations world-wide, legendary MIDAS consoles such as the XL4 and Heritage H3000 quickly became industry standards.
MIDAS has earned their impeccable reputation due to their no-compromise approach for audio and build quality and in particular for their Award-winning products which are considered by industry experts as the industry’s best sounding designs. Building on this legacy, the XL8 and PRO Series of Live Mixing Systems continue this great heritage of Award-winning audio quality.
KLARK TEKNIK is proud to incorporate MIDAS designed transformers for the ultimate in high-quality audio reproduction in both live and studio environments. Find out more about MIDAS’ amazing legacy by visiting their extensive website.
High Headroom Design
A custom instrumentation-grade input circuit was designed for the DI 10A using advanced analogue design techniques to create the very high input impedance required by passive guitar and bass pickups, whilst keeping the actual component values low to minimise noise. This innovative approach to circuit design produces a very low noise floor, which combined with the high clipping point creates an unrivalled dynamic range in a +48 V phantom powered DI Box.
Connectivity & More
DI 10A PRO DI ACTIVE features genuine high quality Neutrik* XLR and high impedance 1/4" TS connectors to maintain the highest signal integrity. The Input connectors accept balanced and unbalanced signals over TRS, TS or XLR cables with plugs, with the Thru jack passing an unbalanced 1/4" TS signal to local amps/monitors. The Output XLR jack sends a balanced version of the Input signal to your mixing board or other processing device.
Input Pad, Power & Earth Lift Switches
Features a highly versatile input Pad, the DI 10A easily accommodates signal levels ranging from +10 to +50 dBu. The Earth Lift switch separates the input and output grounds, eliminating earth loops between equipment on different mains electricity supplies. Power is managed via a dedicated switch with an LED indicator that indicates the current operating state: battery power active = LED blinks; battery power off = LED off, and phantom power active = LED constantly on.
Versatility
The DI 10A PRO DI ACTIVE provides maximum versatility, frequency response from 10 Hz to 90 kHz (±3 dB), MIDAS custom-design transformers for the ultimate signal integrity, and much more – all in a road-ready enclosure that stands ready for your input.
Visit your local KLARK TEKNIK supplier to try out the DI 10A PRO DI ACTIVE, or get yours online today. Your ears can tell the difference.
Passive Stereo DI Box with Midas Transformers and Extended Dynamic Range
Product Features
Passive Stereo DI Box for general purpose and multimedia applications
Custom-built Midas transformers for highest signal integrity
High headroom design offers superior sound quality
Passive design does not require any power supply
Stereo input on 1/4", 1/8" TRS and RCA connectors
Switchable input attenuation for guitar, line and speaker levels
High quality Neutrik* XLR connectors
Earth Lift switches for input and output eliminate ground loop problems
Fully transformer-isolated design ensures electrical separation
Ultra-low noise and ultra-linear system for highest signal integrity
Aluminium extrusion casing with protective rubber corners
Compact and rugged design
Designed and engineered in the U.K.
PRO DI AV 2 DI 22P
Building on KLARK TEKNIK’s storied legacy of highest-quality direct injection devices, the DI 22P PRO DI AV 2 offers the same high headroom, dynamic response and sonic clarity you have come to expect. DI 22P combines many of the outstanding features of the DI 20P and DI 10P direct boxes into one powerful tool that should be in every audio engineers kit. The extremely versatile DI 22P accepts dual instrument, line and speaker levels, plus also accommodates MP3, CD players, keyboard or drum submixers, and a variety of other stereo sources, and faithfully reproduces the character of electric and acoustic instruments, allowing far more of the detail of musical performances to be captured. A passive device, the DI 22P does not require any form of external power to complete its mission. Equipped with custom-built MIDAS transformers and switchable input Pads, the DI 22P is the perfect choice for premium-grade professional audio and multimedia applications.
MIDAS – The Legend in Sound Quality
Ever since its formation in the 1970s, MIDAS has had a long history of innovation and leadership in the world of audio mixing consoles. Employed by the most famous touring acts and installations world-wide, legendary MIDAS consoles such as the XL4 and Heritage H3000 quickly became industry standards.
MIDAS has earned their impeccable reputation due to their no-compromise approach for audio and build quality and in particular for their Award-winning products which are considered by industry experts as the industry’s best sounding designs. Building on this legacy, the XL8 and PRO Series of Live Mixing Systems continue this great heritage of Award-winning audio quality.
KLARK TEKNIK is proud to incorporate MIDAS designed transformers for the ultimate in high-quality audio reproduction in both live and studio environments. Find out more about MIDAS’ amazing legacy by visiting their extensive website.
Compact & Rugged Construction
The ultra-compact DI 22P is built to handle the rigours of life on the road via a thick and rugged aluminium extrusion that protects the electronics. The enclosure’s roadworthiness is further enhanced through the implementation of sturdy rubber corner bumpers.
High Headroom Design
A custom instrumentation-grade input circuit was designed for the DI 22P using advanced analogue design techniques to create the ideal input impedance match. This innovative approach provides an ultra-low noise, low harmonic and phase distortion input stage with a ruler-flat frequency response that ranges from 20 Hz to 30 kHz (±1 dB).
Connectivity & More
DI 22P PRO DI AV 2 Inputs are: 2 x 1/4" TS; 2 x RCA ; and 1 x 1/8" TRS connectors, which can accommodate virtually any type of signal – for the utmost in versatility. The genuine Neutrik* Output XLR jacks send balanced versions of the input signals to your mixing board or other processing device.
Input Pad, Earth Lift Switch & More
A -15 dB input Pad enables the DI 22P to easily accept a wide range of input signals including guitar, line and speaker levels (up to 30 dBu). The onboard Earth Lift switches separate the input and output grounds, eliminating earth loops between equipment on different mains electricity supplies. DI 22P’s fully transformer-isolated design further ensures pristine performance – even in large-scale production environments.
Versatility
The DI 22P PRO DI AV 2 provides maximum versatility with frequency response from 20 Hz to 30 kHz (±1 dB), MIDAS custom-design transformers for the ultimate signal integrity, and much more – all in a road-ready enclosure that stands ready for your input.
