ARTEMIS-12PM Active 12" co-axial stage monitor
Description
The ARTEMIS 12PM is an active 2-way coaxial stage monitor. The ARTEMIS series of monitors comprise of 3 models (10″, 12″ and 15”) equipped with Class D amplifiers + Class AB amplifiers delivering a combined 250 Watts RMS (for ARTEMIS 10PM) or 350 Watts RMS (for ARTEMIS 12PM and 15PM) The monitor wedge’s coaxial design, provides an even crystal clear sound reproduction.
Features
Active Coaxial stage monitor
Pole mountable for FOH
Front sturdy grille design
Integrated side handles
Specification
Frequency Response
53Hz – 18kHz
Max SPL
123 dB
Low-freq. Transducer
12″ Woofer 2.36″ Voice Coil
High-freq. Transducer
1″ Exit 1.35″ Compression Driver
Coverage
Low-Frequency Amplifier
Class-D 300W RMS – 600W Peak
High-Frequency Amplifier
Class-AB 50W RMS – 100W Peak
AC Mains
220/240V ? 50/60Hz
Power Consumption (Average/Peak)
250W / 500W
Fuse
T6.3AL-250V
DSP
Input Connections
1x XLR/TRS Multicon connector,
LINK Connectors
?1x XLR Link Output with Mono/Stereo selection
Housing Material
Plywood
Grille
Steel/1mm
Flyable
No
Handles
2 – Integrated 1 on each side
Tripod/Pole Hole
Standard D35mm
Speaker Size (WxHxD)
521 x 565 x 448 mm
Packing Size (WxHxD)
Speaker Weight
16.84 kg
PWB-12A Battery operated 12 active speaker
Description
The PWB Series by PowerWorks is an affordable Active Battery Powered 12" Speaker Trolley Speaker for easy transportability.
Features
12″ WOOFER + 1″ COMPRESSION DRIVER 800 WATT ACTIVE POLYPROPYLENE MOULDED SPEAKER
Active Battery Powered Full-Range Speaker with Wireless Microphone
Equipped with a 12″ woofer and a 1″ compression driver
Class AB power amplifier
Power: 400 W RMS, 800 W peak
2 Way Active Speaker
2 x Handles on sides
Trolley System with wheels and one top handle for easy transportability
MP3 player with Bluetooth receiver, blue LCD and IR remote control
SD card slot and USB input
Stream music wirelessly from your mobile devices (e.g. smartphone, tablet) via Bluetooth
Control: IR remote control; Bluetooth
2 mic inputs with level controls
1 wireless mic level control
1 wireless hand held microphone (included)
Line input, 2x RCA
Echo control
MP3 Volume Control
Mix output, 2x RCA
5 Bank Graphic Equaliser
Master control with clip and power LED
12v Input for external Battery use
Battery charge indicator for internal Battery
Internal Battery rechargeable with 2,5 hour battery life
Stable polypropylene housing with protective grille and handles
35mm Flange for Speaker stand installation
Can be used as floor monitor, standing, on a speaker stand or wall bracket.
35mm standard pole mount
Max. SPL (sound pressure level): 126 dB
Dispersion pattern: 90 x 60 Symmetric Horn
Dimensions Carton: 440 x 440 x 686 mm
Nett Weight: 15,3 kg
Gross Weight: 18,2 kg
The system is ideal for use in Houses of Worship, Funerals, Schools, Aerobics Studios and Gyms, Conference venues, Bands, DJ’s and Presentations.
Specifications
Power supply:
230 V AC, 50 Hz
Power connection:
Mains input IEC connector (M) mounting version Power supply cord with safety plug (provided)
Rated power:
400 W RMS
Program power:
800 W
Frequency range:
50 – 20000 Hz
Max. SPL:
126 dB
Control:
IR remote control
Audio player:
USB + SD + Bluetooth
Echo
Built in Echo effect with level control
Equaliser:
5-band graphic equaliser
Attachment system:
35mm and 4 x M8 Flying Points
Connections:
Input: 2 x Microphone 6.3 mm plug (unbalanced.) with level control
Input: 1 x line via Stereo RCA with level control
Input: 1 x wireless microphone built in with level control
Output: 2 x RCA Mix Output
Format:
MP3, WAV
Number of files:
max. 999
Available storage media:
USB devices/SD cards (FAT 32)
Speakers:
1 x woofer (12″) and 1″ Compression Driver
Horn
90 x 60 Symmetric Horn
Battery
Built in rechargeable battery with 2,5 hours battery life
Handles
2 x Handles on sides
Trolley
Trolley system with wheel and telescopic handle on top
Width:
44 cm
Height:
68 cm
Depth:
44 cm
Weight:
15.3 kg
Remote control
Battery:
1 x Button cell 3.0 V CR2025 lithium manganese built-in
ARTEMIS-15SB Active 15" sub woofer
Description
The complete range of ARTEMIS Sub-Woofers has a rugged, multi-layered painted black Plywood birch enclosure for the performance characteristics that only wood can offer.
Features
The ARTEMIS Bass Reflex Series has 3 dedicated compact Sub-Woofers which provide substantial Bass for all the ARTEMIS & APOLLO Series of Loudspeakers.
An excellent solution for permanent installations and mobile use. The ARTEMIS Models 12SB, 15SB & 18SB, are a top choice for hiring, installation and mobile use. Best of all, they sound great, delivering outstanding bass response which is loud and punchy.
These active subwoofers are equipped with 12”, 15” & 18” high-excursion woofers all with 4″ Voice Coils.
Sturdy and stylish birch plywood enclosures with metal grille and dual bass ports.
Equipped with a Class D amp and switching power supply they deliver massive power up to 1000W with great efficiency.
All models feature a full DSP Control and balanced Input/Output/Link connections .
All models feature M20 speaker pole mount and 35mm speaker pole mount
4 recessed handles (12”, 15″ & 18”)
4 wheels mount on 15” version for portable sound purposes and easy carriage.
Specifications
Equipped with a 1x 15″ woofer 4″ Voice Coil
Power: 1000 Watts RMS / 2000 Watts Peak
Class D power amplifier
Frequency response: 35-150 Hz
Maximum SPL (sound pressure level): 128 dB
Housing: 18mm MDF Multi-Layered Painted Black
Inputs: 2 x Multi-combo XLR and 6.3mm TRS? line-level inputs
Outputs: 2 x XLR outputs
Stand flange mount: 35 mm & M20
Dimensions: 710(H) x 565(W) x 695(D) mm
Weight: 45,3 kg
Optional cover available
Optional Casters available
ARTEMIS-12SB Active 12" sub woofer
Description
The ARTEMIS Bass Reflex Series has 3 dedicated compact Sub-Woofers which provide substantial Bass for all the ARTEMIS & APOLLO Series of Loudspeakers. An excellent solution for permanent installations and mobile use. The ARTEMIS Models 12SB, 15SB & 18SB, are a top choice for hiring, installation and mobile use.
Best of all, they sound great, delivering outstanding bass response which is loud and punchy. These active subwoofers are equipped with 12”, 15” & 18” high-excursion woofers all with 4″ Voice Coils. Sturdy and stylish MDF enclosures with metal grille and dual bass ports. Equipped with a Class D amp and switching power supply they deliver massive power up to 1000W with great efficiency. All models feature a full DSP Control and balanced Input/Output/Link connections.
Features
Equipped with a 1x 12″ woofer 4″ Voice Coil
Power: 800 Watts RMS / 1600 Watts Peak
Class D power amplifier
Frequency response: 40-150 Hz
Maximum SPL (sound pressure level): 124 dB
Housing:? 18mm MDF Multi-Layered Painted Black
Inputs: 2 x Multi-combo XLR and 6.3mm TRS? line-level inputs
Outputs: 2 x XLR outputs
Stand flange mount: 35 mm & M20
Dimensions: 655(H) x 485(W) x 625(D) mm
Weight: 32,2 kg
Optional cover available
Specifications:
Frequency Response40Hz – 150KHz
Max SPL 124 dB
Amplifier Class D
Power Output 800 Watts
2 x Combo XLR and 6.3mm TRS line-level inputs
Link Out: 2 x XLR outputs
Full DSP Control
18mm MDF Multi-Layered Painted Black
Height 655 mm
Width 485 mm
Depth 625 mm
Weight 32.2 kg
ARTEMIS-15PD Active 15 speaker with DSP
Description
The ARTEMIS Series of Active Plywood enclosure have been designed as a high performance, light weight Audio Solution. There are 4 models in the range 8″, 10″, 12″ and 15″. The speaker box can also be used as a stage monitor. Equipped with High Power Woofers and compression drivers. The speakers deliver high definition audio with a wide frequency response.
Features
Bi-Amped Active Speaker
600W RMS – 1200W Peak Power
Amplifier
Class-D (low-frequencies); Class-AB (high-frequencies)
Graphic back-lit display DSP Display
Sturdy and Lightweight Polypropylene Enclosure with black anti-scratch paint
Standard D35mm tripod / pole hole
30° and 45° Stage Monitor Usable Angles
Specifications
Frequency Response
43Hz – 19kHz / -10dB
Max SPL
136 dB
Low-freq. Transducer
15″ Woofer 2.36″ Voice Coil
High-freq. Transducer
1.75″ Compression Driver
Coverage
H90? x V60?
Crossover Frequency
2,6kHz
Low-Frequency Amplifier
Class-D 550W RMS – 1100W Peak
High-Frequency Amplifier
Class-AB 50W RMS – 100W Peak
Power Consumption
450W
Fuse
T3.15A-250V
AC Mains
220/240V ? 50/60Hz
Input Connections
2 x COMBO (XLR + 1/4″ Jack, balanced)+3,5mm Jack
Output Connections
1 x XLR (Mix output, balanced)
Housing material
Plywood Cabinet
1.2mm Steel Grille
Handles
2 on sides
Tripod/Pole Hole
Duo-tilt 0? and 7?
Stage Monitor Use Angle
30? and 45?
Speaker Size (WxHxD)
505 x 778 x 525 mm
Packing Size (WxHxD)
515 x 790 x 535 mm
Speaker Weight
28.2 kg
Carton Weight
29.5 kg
ARTEMIS-12PD Active 12 speaker with DSP
Description
12” 1200W Peak 2-way Powered Loudspeakers with DSP.
Features
Discover the ARTEMIS Series, an exceptional lineup of active plywood enclosures engineered to deliver superior audio performance in a lightweight design. With four models ranging from 8″ to 15″, these speakers are versatile and can also function as stage monitors.
High Definition Audio: Equipped with high-power woofers and compression drivers, ARTEMIS speakers provide crystal-clear audio with a broad frequency response.
Bi-Amped Active Speaker: Enjoy 600W RMS and 1200W peak power, driven by Class-D for low frequencies and Class-AB for high frequencies.
Graphic Back-lit DSP Display: Easily navigate settings and adjustments with the intuitive display.
Sturdy and Lightweight Design: Crafted with polypropylene and coated with black anti-scratch paint for durability.
Versatile Mounting Options: From tripod/pole holes to stage monitor angles, ARTEMIS speakers offer flexible setup possibilities.
Description:
Experience clear sound for mobile and installed systems with ARTEMIS Series 2-way active sound-reinforcement loudspeakers. Offering 1200W peak power and ease-of-use DSP, these 12″ powered loudspeakers are perfect for various applications.
Backed by two integrated amplifiers delivering 600W of Class D/Class AB power, ARTEMIS speakers feature advanced DSP tuning for optimal performance. The combination of Class D and Class A/B amplifiers ensures efficient power distribution across the frequency range, resulting in up to 120 dB SPL of clear sound from 50 Hz to 19 kHz.
Customize your sound effortlessly with the intuitive DSP, and enjoy versatile mounting options for various setups. Whether it’s flying vertically or horizontally, mounting on a tripod, or using as a stage monitor, ARTEMIS speakers adapt to your needs with ease.
With flexible inputs, including combo XLR mic/jack inputs and a stereo 3.5mm jack, ARTEMIS speakers accommodate a range of audio sources. Plus, with an onboard mixer and balanced XLR mix output, integrating multiple speakers or an active subwoofer is seamless.
Specifications
Frequency Response
50Hz – 19kHz / -10dB
Max SPL
120 dB
Low-freq. Transducer
12″ Woofer 2.36″ Voice Coil
High-freq. Transducer
1.35″ Compression Driver
Coverage
H90° x V60°
Crossover Frequency
2,8kHz
Low-Frequency Amplifier
Class-D 550W RMS – 1100W Peak
High-Frequency Amplifier
Class-AB 50W RMS – 100W Peak
Power Consumption
450W
Fuse
T3.15A-250V
AC Mains
220/240V – 50/60Hz
Input Connections
2 x COMBO (XLR + 1/4″ Jack, balanced)+3,5mm Jack
Output Connections
1 x XLR (Mix output, balanced)
Housing material
Plywood Cabinet
1.2mm Steel Grille
Handles
2 on sides
Tripod/Pole Hole
Duo-tilt 0° and 7°
Stage Monitor Use Angle
30° and 45°
Speaker Size (WxHxD)
450 x 687 x 465 mm
Packing Size (WxHxD)
490 x 695 x 475 mm
Speaker Weight
22.4 kg
Carton Weight
23.4 kg
