ARTEMIS-12PM Active 12" co-axial stage monitor
Description
The ARTEMIS 12PM is an active 2-way coaxial stage monitor. The ARTEMIS series of monitors comprise of 3 models (10″, 12″ and 15”) equipped with Class D amplifiers + Class AB amplifiers delivering a combined 250 Watts RMS (for ARTEMIS 10PM) or 350 Watts RMS (for ARTEMIS 12PM and 15PM) The monitor wedge’s coaxial design, provides an even crystal clear sound reproduction.
Features
- Active Coaxial stage monitor
- Pole mountable for FOH
- Front sturdy grille design
- Integrated side handles
Specification
|
Frequency Response
|
53Hz – 18kHz
|
|
Max SPL
|
123 dB
|
|
Low-freq. Transducer
|
12″ Woofer 2.36″ Voice Coil
|
|
High-freq. Transducer
|
1″ Exit 1.35″ Compression Driver
|
|
Coverage
|
|
|
Low-Frequency Amplifier
|
Class-D 300W RMS – 600W Peak
|
|
High-Frequency Amplifier
|
Class-AB 50W RMS – 100W Peak
|
|
AC Mains
|
220/240V ? 50/60Hz
|
|
Power Consumption (Average/Peak)
|
250W / 500W
|
|
Fuse
|
T6.3AL-250V
|
|
DSP
|
|
|
Input Connections
|
1x XLR/TRS Multicon connector,
|
|
LINK Connectors
|
?1x XLR Link Output with Mono/Stereo selection
|
|
Housing Material
|
Plywood
|
|
Grille
|
Steel/1mm
|
|
Flyable
|
No
|
|
Handles
|
2 – Integrated 1 on each side
|
|
Tripod/Pole Hole
|
Standard D35mm
|
|
Speaker Size (WxHxD)
|
521 x 565 x 448 mm
|
|
Packing Size (WxHxD)
|
|
|
Speaker Weight
|
16.84 kg
|
