Hybrid 15" 2-Way Full-Range Active Speaker [PB15A-DSP]

Hybrid PB15A-DSP 15-Inch Bi-Amp Active PA Speaker

The Hybrid PB15A-DSP is a 15-inch, two-way active full-range PA speaker designed for live performances and installed sound applications. Its bi-amplified Class-D system delivers 200 W RMS to the low-frequency section and 50 W RMS to the high-frequency section. A 15-inch woofer with a 3-inch voice coil handles the low frequencies, while a 1.75-inch titanium-diaphragm compression driver reproduces the high-frequency range. The system covers a stated frequency range of 50 Hz–18 kHz.

Integrated DSP provides Flat, Music, Bass and Sub presets, together with savable scenes for user EQ and input settings. Bluetooth 5.3 with True Wireless Stereo functionality supports compatible wireless playback and speaker pairing. Two combination XLR/6.35 mm microphone or line inputs accommodate compatible wired sources, while a 3.5 mm auxiliary input offers another playback option. An XLR output supports connection to compatible downstream audio equipment. The speaker operates directly from a 220–240 VAC mains supply.

Features

• 15-inch, two-way active full-range PA speaker
• Bi-amplified Class-D design
• 200 W + 50 W RMS continuous power
• 15-inch woofer with a 3-inch voice coil
• 1.75-inch titanium-diaphragm high-frequency driver
• Integrated DSP with four application presets
• Savable scenes for user EQ and input settings
• Bluetooth 5.3
• True Wireless Stereo functionality
• Two combination microphone/line inputs
• 3.5 mm auxiliary input
• XLR audio output
• 90° × 60° stated sound coverage

Specifications

System

• Brand: Hybrid
• Model: PB15A-DSP
• Product type: Active full-range PA speaker
• System configuration: Two-way, bi-amplified
• Amplifier class: Class D
• Continuous power: 200 W LF + 50 W HF
• Signal processing: DSP
• Frequency range: 50 Hz–18 kHz
• Stated sensitivity/SPL: 122 dB
• Sound coverage: 90° horizontal × 60° vertical
• Power supply: 220–240 VAC, 50/60 Hz

Drivers

• Low-frequency driver: 15-inch woofer
• Woofer magnet: 60 oz
• Woofer voice coil: 3 inches
• Woofer impedance: 4 ohms
• High-frequency driver: 1 × 1.75-inch titanium-diaphragm driver
• High-frequency driver impedance: 8 ohms

DSP and Connectivity

• DSP presets: Flat, Music, Bass and Sub
• User scenes: Savable EQ and input settings
• Bluetooth: Version 5.3
• Wireless pairing: True Wireless Stereo
• Inputs: 2 × combination XLR/6.35 mm microphone/line
• Auxiliary input: 1 × 3.5 mm
• Output: XLR

Dimensions & Weight

• Dimensions: 36.95 × 42.35 × 69.1 cm (Length × Width × Height)
• Weight: 19 kg

What’s in the Box?

• 1 × Hybrid PB15A-DSP active PA speaker

Warranty?

• 12 Months
